Re: [Xylo-SDR] Cyclone II board

Thanks again, its now fixed!

Jack B. "gunny" McAlister   KE7FMD   gunny@cableone.net

-------Original Message-------

From: dtx
Date: 12/11/05 16:26:59
Subject: Re: [Xylo-SDR] Cyclone II board

Just FYI but your computer seems to think it is march 13, 05 ;- )

Gary WA6DTX

Jack McAlister wrote:

> explanation of the Manhatten style construction. This is a better
> construction method than "ugly" construction.
>
> Jack B. "gunny" McAlister   KE7FMD   gunny@cableone.net
>
> /-------Original Message-------/
>
> /*From:*/ Leon Heller <mailto:leon.heller@bulldoghome.com>
> /*Date:*/ 12/11/05 12:38:18
> /*To:*/ Xylo-SDR Discussion <mailto:xylo-sdr@lists.ae5k.us>
> /*Subject:*/ Re: [Xylo-SDR] Cyclone II board
>
>
> ----- Original Message -----
> *From:* KD5NWA <mailto:kd5nwa@cox.net>
> *To:* Xylo-SDR Discussion <mailto:xylo-sdr@lists.ae5k.us>
> *Sent:* Sunday, December 11, 2005 7:13 PM
> *Subject:* Re: [Xylo-SDR] Cyclone II board
>
> Your board sounds good, and that is a good price for the chip.
>
> All this new technology has one drawback, you must get a PCB board
> made because it's impossible to breadboard without a PCB to solder the
> chips to.
>
> Right now when I need a PCB board, I sketch it with pencil to figure
> the line layout, then use Photoshop to create the 10X art, which after
> verification I print on a piece of photo paper and use heat transfer
> to a PCB board.
>
> It works well for small boards, but it's a very tedious method to make
> a larger or complicated board.
>
> I guess I should have learned to use a Software package like Kicad or
> Eagle some time back when I had no need for them, so now I would be
> able to lay out my own PCB's. Hindsight is almost always 20/20 :'(
>
> For simple home-made boards I use Pulsonix to print a transparency on
> JetStar film in an inkjet printer and use it with positive resist
> coated material, exposing to UV, developing in sodium hydroxide
> solution, and etching in ferric chloride. More complicated boards I
> get made for me from the Gerber output files. It isn't expensive, even
> for four-layer boards.
>
> Leon
>
>
>
>
>
>
>------------------------------------------------------------------------
>
